Criogénica de muñón con entrada superior Válvula de bola montada

C52


Rango de tamaño
1/2”- 6” (DN15-DN150)
Rango de presión
Class #300, 50 bar, 750 psi

Características de diseño
• Montada en muñón con entrada superior, manual o accionada
• Asiento único DPE – Totalmente bidireccional
• Paquete de integridad Total HermetiX
• Extremos extendidos con soldadura a tope

Kit opcional de buje extendido
• Extiende la parte superior de la válvula por encima del límite del aislamiento
• Permite el acceso y mantenimiento de las piezas interiores sin desmontar el aislamiento



Leer más

Special mechanical design and construction

  • Solid one-piece high torque durable stem.
  • Tight stem-to-ball directional engagement, ensures relief hole alignment.
  • Strict materials and manufacturing tolerances control.

Efficient heat transfer

  • A narrow space between the extension ID and the stem OD allows the
    stem seal to remain at an ambient temperature.

No-Trap Cavity

  • Relief hole on the upstream sphere of the ball to prevent pressure buildup in the cavity.
  • Single-side or self-pressure-relief sealing for bidirectional full pressure service.

Flexible bonnet installation angle

  • Up to 45° from the vertical axis for the 12” bonnet (per BS6364 guidelines).
  • Up to 15° from the vertical axis for the 6” bonnet (not BS6364 compliant).

Flow direction indicators (for valves with preferred flow direction)

  • Highly visible arrows on body and bonnet top.
  • “T” mark on the stem, showing relief hole direction.

Double isolation / double block and bleed designs available upon request
